Danfoss VLT AutomationDrive FC 302 Instruction Manual page 100

Programming
6.3.16 15-** Drive Information
Par. Parameter description
No. #
15-0* Operating Data
15-00 Operating hours
15-01 Running Hours
15-02 kWh Counter
15-03 Power-ups
15-04 Over Temps
15-05 Over Volts
15-06 Reset kWh Counter
15-07 Reset Running Hours Counter
15-1* Data Log Settings
6 6
15-10 Logging Source
15-11 Logging Interval
15-12 Trigger Event
15-13 Logging Mode
15-14 Samples Before Trigger
15-2* Historic Log
15-20 Historic Log: Event
15-21 Historic Log: Value
15-22 Historic Log: Time
15-3* Fault Log
15-30 Fault Log: Error Code
15-31 Fault Log: Value
15-32 Fault Log: Time
15-4* Drive Identification
15-40 FC Type
15-41 Power Section
15-42 Voltage
15-43 Software Version
15-44 Ordered Typecode String
15-45 Actual Typecode String
15-46 Adj Freq Dr Ordering No.
15-47 Power Card Ordering No.
15-48 LCP ID Num.
15-49 SW ID Control Card
15-50 SW ID Power Card
15-51 Adj Freq Dr Serial No.
15-53 Power Card Serial Number
15-58 Smart Setup Filename
15-59 CSIV Filename
15-6* Option Ident
15-60 Option Mounted
15-61 Option SW Version
15-62 Option Ordering No
15-63 Option Serial No
15-70 Option in Slot A
15-71 Slot A Option SW Version
15-72 Option in Slot B
15-73 Slot B Option SW Version
15-74 Option in Slot C0
15-75 Slot C0/E0 Option SW Version
15-76 Option in Slot C1
15-77 Slot C1/E1 Option SW Version
15-8* Operating Data II
15-80 Fan Running Hours
15-81 Preset Fan Running Hours
15-89 Configuration Change Counter
15-9* Parameter Info
98
Instruction Manual
Default value
0 h
0 h
0 kWh
0 N/A
0 N/A
0 N/A
[0] Do not reset
[0] Do not reset
0
ExpressionLimit
[0] FALSE
[0] Log always
50 N/A
0 N/A
0 N/A
0 ms
0 N/A
0 N/A
0 s
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
ExpressionLimit
ExpressionLimit
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 h
0 h
0 N/A
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
4-set-up Change Conver-
during sion index
operation
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
2 set-ups TRUE
2 set-ups TRUE
1 set-up TRUE
2 set-ups TRUE
2 set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
1 set-up TRUE
1 set-up FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
Type
74 Uint32
74 Uint32
75 Uint32
0 Uint32
0 Uint16
0 Uint16
- Uint8
- Uint8
- Uint16
-3 TimD
- Uint8
- Uint8
0 Uint8
0 Uint8
0 Uint32
-3 Uint32
0 Uint16
0 Int16
0 Uint32
0 VisStr[6]
0 VisStr[20]
0 VisStr[20]
0 VisStr[5]
0 VisStr[40]
0 VisStr[40]
0 VisStr[8]
0 VisStr[8]
0 VisStr[20]
0 VisStr[20]
0 VisStr[20]
0 VisStr[10]
0 VisStr[19]
0 VisStr[20]
0 VisStr[16]
0 VisStr[30]
0 VisStr[20]
0 VisStr[8]
0 VisStr[18]
0 VisStr[30]
0 VisStr[20]
0 VisStr[30]
0 VisStr[20]
0 VisStr[30]
0 VisStr[20]
0 VisStr[30]
0 VisStr[20]
74 Uint32
74 Uint32
0 Uint16
MG37A222
