6.3.18 17-** Motor Feedb.Option
Par. Parameter description
No. #
17-1* Inc. Enc. Interface
17-10 Signal Type
17-11 Resolution (PPR)
17-2* Abs. Enc. Interface
17-20 Protocol Selection
17-21 Resolution (Positions/Rev)
17-24 SSI Data Length
17-25 Clock Rate
17-26 SSI Data Format
17-34 HIPERFACE Baud rate
6 6
17-5* Resolver Interface
17-50 Poles
17-51 Input Voltage
17-52 Input Frequency
17-53 Transformation Ratio
17-56 Encoder Sim. Resolution
17-59 Resolver Interface
17-6* Monitoring and App.
17-60 Feedback Direction
17-61 Feedback Signal Monitoring
6.3.19 18-** Data Readouts 2
Par. Parameter description
No. #
18-3* Analog Readouts
18-36 Analog Input X48/2 [mA]
18-37 Temp. Input X48/4
18-38 Temp. Input X48/7
18-39 Temp. Input X48/10
18-6* Inputs & Outputs 2
18-60 Digital Input 2
18-9* PID Readouts
18-90 Process PID Error
18-91 Process PID Output
18-92 Process PID Clamped Output
18-93 Process PID Gain Scaled Output
102
Instruction Manual
Default value
[1] TTL (5V, RS4222)
1024 N/A
[0] None
ExpressionLimit
13 N/A
ExpressionLimit
[0] Gray code
[4] 9600
2 N/A
7 V
10 kHz
0.5 N/A
[0] Disabled
[0] Disabled
[0] Clockwise
[1] Warning
Default value
0 N/A
0 N/A
0 N/A
0 N/A
0 N/A
0 %
0 %
0 %
0 %
