Programming
Par. Parameter description
No. #
1-64 Resonance Damping
1-65 Resonance Damping Time Constant
1-66 Min. Current at Low Speed
1-67 Load Type
1-68 Minimum Inertia
1-69 Maximum Inertia
1-7* Start Adjustments
1-70 PM Start Mode
1-71 Start Delay
1-72 Start Function
1-73 Flying Start
1-74 Start Speed [RPM]
6 6
1-75 Start Speed [Hz]
1-76 Start Current
1-8* Stop Adjustments
1-80 Function at Stop
1-81 Min Speed for Function at Stop [RPM]
1-82 Min Speed for Function at Stop [Hz]
1-83 Precise Stop Function
1-84 Precise Stop Counter Value
1-85 Precise Stop Speed Compensation Delay
1-9* Motor Temperature
1-90 Motor Thermal Protection
1-91 Motor External Fan
1-93 Thermistor Resource
1-94 ATEX ETR cur.lim. speed reduction
1-95 KTY Sensor Type
1-96 KTY Thermistor Resource
1-97 KTY Threshold level
1-98 ATEX ETR interpol. points freq.
1-99 ATEX ETR interpol points current
82
Instruction Manual
Default value
100 %
5 ms
ExpressionLimit
[0] Passive load
ExpressionLimit
ExpressionLimit
[0] Rotor Detection
0 s
[2] Coast/delay time
ExpressionLimit
ExpressionLimit
ExpressionLimit
0 A
[0] Coast
ExpressionLimit
ExpressionLimit
[0] Precise ramp stop
100000 N/A
10 ms
ExpressionLimit
ExpressionLimit
[0] None
0 %
[0] KTY Sensor 1
[0] None
80 °C
ExpressionLimit
ExpressionLimit
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
4-set-up FC 302 Change
only during
operation
All set-ups TRUE
All set-ups TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups x FALSE
All set-ups x FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
2 set-ups x TRUE
All set-ups x TRUE
All set-ups x TRUE
1 set-up x TRUE
1 set-up x TRUE
2 set-ups x TRUE
Conver- Type
sion index
0 Uint16
-3 Uint8
0 Uint32
- Uint8
-4 Uint32
-4 Uint32
- Uint8
-1 Uint8
- Uint8
- Uint8
67 Uint16
-1 Uint16
-2 Uint32
- Uint8
67 Uint16
-1 Uint16
- Uint8
0 Uint32
-3 Uint8
- Uint8
- Uint16
- Uint8
-1 Uint16
- Uint8
- Uint8
100 Int16
-1 Uint16
0 Uint16
