Introduction
2 2
1 Contactor
2 RFI filter
3 Line power AC power input terminals
Figure 2.5 Frame Size F18 Options Cabinet
*The options cabinet is not optional for the LHD. The ancillary equipment is stored in the cabinet.
10
Instruction Manual
5
4
3
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
1
2
4 Circuit breaker or disconnect (if purchased)
5 AC line power/line fuses (if purchased)
