Danfoss VLT AutomationDrive FC 302 Instruction Manual page 26

Installation
3 3
1 Front View
2 Left Side View
3 Right Side View
Figure 3.12 Frame Size F18 Inverter Cabinet
The connector plate is 1.65 in [42 mm] below .0 level. Shown are the left side view, front, and right.
24
Instruction Manual
1
6
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
2
4 Brake Terminals
5 Ground bar
4
308.3 [12.1]
253.1 [10.0]
180.3 [7.1]
5
.0 [.0]
44.40 [1.75]
244.40 [9.62]
4
3
MG37A222
