Danfoss VLT AutomationDrive FC 302 Instruction Manual page 105

Programming
6.3.20 30-** Special Features
Par. Parameter description
No. #
30-0* Wobbler
30-00 Wobble Mode
30-01 Wobble Delta Frequency [Hz]
30-02 Wobble Delta Frequency [%]
30-03 Wobble Delta Freq. Scaling Resource
30-04 Wobble Jump Frequency [Hz]
30-05 Wobble Jump Frequency [%]
30-06 Wobble Jump Time
30-07 Wobble Sequence Time
30-08 Wobble Up/Down Time
30-09 Wobble Random Function
30-10 Wobble Ratio
30-11 Wobble Random Ratio Max.
30-12 Wobble Random Ratio Min.
30-19 Wobble Delta Freq. Scaled
30-2* Adv. Start Adjust
30-20 High Starting Torque Time [s]
30-21 High Starting Torque Current [%]
30-22 Locked Rotor Protection
30-23 Locked Rotor Detection Time [s]
30-8* Compatibility (I)
30-80 d-axis inductance (Ld)
30-81 Brake Resistor (ohm)
30-83 Speed PID Proportional Gain
30-84 Process PID Proportional Gain
MG37A222
Instruction Manual
Default value 4-set-up
[0] Abs. Freq., Abs. Time All set-ups
5 Hz All set-ups
25 % All set-ups
[0] No function All set-ups
0 Hz All set-ups
0 % All set-ups
ExpressionLimit All set-ups
10 s All set-ups
5 s All set-ups
[0] Off All set-ups
1 N/A All set-ups
10 N/A All set-ups
0.1 N/A All set-ups
0 Hz All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit 1 set-up
ExpressionLimit All set-ups
0.100 N/A All set-ups
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
FC Change Conver-
302 during sion index
only operation
FALSE -
TRUE -1
TRUE 0
TRUE -
TRUE -1
TRUE 0
TRUE -3
TRUE -1
TRUE -1
TRUE -
TRUE -1
TRUE -1
TRUE -1
FALSE -1
x TRUE -2
x TRUE -1
x TRUE -
x TRUE -2
x FALSE -6
TRUE -2
TRUE -4
TRUE -3
Type
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint16
6 6
Uint8
Uint8
Uint8
Uint8
Uint16
Uint16
Uint32
Uint8
Uint8
Int32
Uint32
Uint32
Uint16
