Warnings and Alarms
No. Description
309 Power ground fault
311 Switch. freq. limit
312 CT range
314 Auto CT interrupt
315 Auto CT error
316 CT location error
317 CT polarity error
318 CT ratio error
Table 9.3 Alarm/Warning Code List
A trip is the action when an alarm has appeared. The trip coasts the motor and can be reset by pressing [Reset] or make a
reset by a digital input (parameter group 5-1* Digital Inputs [1] Reset). The original event that caused an alarm cannot
damage the adjustable frequency drive or cause dangerous conditions. A trip lock is an action that occurs in conjunction
with an alarm, which may cause damage to the adjustable frequency drive or connected parts. A trip lock situation can only
be reset by power cycling.
Warning
Alarm
Trip locked
Table 9.4 LED Indicator Lights
MG37A222
Instruction Manual
Warning Alarm/Trip
X X
X
X
X
X
X
X
X
LED indication
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
Alarm/Trip Lock Parameter Reference
yellow
flashing red
yellow and red
