General Technical Data - Filter - Danfoss VLT AutomationDrive FC 302 Instruction Manual

Specifications
Control card performance
Scan interval
Control card, USB serial communication
USB standard
USB plug
NOTICE!
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
The USB connection is not galvanically isolated from ground protection. Use only isolated laptop/PC as connection to
the USB connector on the adjustable frequency drive or an isolated USB cable/drive.
Protection and Features:
•
Electronic thermal motor protection against overload.
•
Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips if the temperature
reaches a predefined level. An overload temperature cannot be reset until the temperature of the heatsink is
below the allowed values.
•
The adjustable frequency drive is protected against short-circuits on motor terminals U, V, W.
•
If a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
•
Monitoring of the intermediate circuit voltage ensures that the adjustable frequency drive trips if the intermediate
circuit voltage is too low or too high.
•
The adjustable frequency drive is protected against ground faults on motor terminals U, V, W.

11.4 General Technical Data - Filter

11 11
Frame size
Voltage [V]
Current, RMS [A]
Peak current [A]
Response time [ms]
Settling time - reactive current control [ms]
Settling time - harmonic current control
(filtering) [ms]
Overshoot - reactive current control [%]
Overshoot - harmonic current control [%]
Table 11.6 Power Ranges (LHD with AF)
160
Instruction Manual
D13 E9
380–480 380–480
120 210
340 595
<0.5
<40
<20
<20
<10
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
USB type B device plug
F18
380–480
330 Nominal value
935 Amplitude value of the current
5 ms
1.1 (full speed)
MG37A222
