General Torque Tightening Values - Danfoss VLT AutomationDrive FC 302 Instruction Manual

Specifications
Frame size
D, E, F
Table 11.20 Transformer Fuse (Line Contactor)
Frame size
D, E, F
Table 11.21 Soft Charge Fuses

11.6 General Torque Tightening Values

For fastening hardware described in this manual, use the torque values in Table 11.22. These values are not intended for
fastening IGBTs. See the instructions included with those replacement parts for correct values.
Shaft Size
M4
M5
M6
M8
M10
M12
Table 11.22 Torque Values
MG37A222
Instruction Manual
Bussmann PN
FNQ-R-3
Bussmann PN
FNQ-R-1
Driver Size Torx/Hex [mm]
T-20/7
T-25/8
T-30/10
T-40/13
T-50/17
18/19
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
Rating
3 A, 600 V
Rating
1 A, 600 V
Torque [Nm]
1.0
2.3
4.0
9.6
19.2
19
Torque [in-lbs]
10
20
35
85
170
170
11
167
11
