Programming
6.3.15 14-** Special Functions
Par.
Parameter description
No. #
14-0* Inverter Switching
14-00 Switching Pattern
14-01 Switching Frequency
14-03 Overmodulation
14-04 PWM Random
14-06 Dead Time Compensation
14-1* Mains On/Off
14-10 Line Failure
14-11 Line Voltage at Line Fault
14-12 Function at Mains Imbalance
14-13 Line Failure Step Factor
14-14 Kin. Backup Time Out
14-15 Kin. Backup Trip Recovery Level
14-16 Kin. Backup Gain
14-2* Trip Reset
14-20 Reset Mode
14-21 Automatic Restart Time
14-22 Operation Mode
14-23 Typecode Setting
14-24 Trip Delay at Current Limit
14-25 Trip Delay at Torque Limit
14-26 Trip Delay at Inverter Fault
14-28 Production Settings
14-29 Service Code
14-3* Current Limit Ctrl.
14-30 Current Lim Ctrl, Proportional Gain
14-31 Current Lim Ctrl, Integration Time
14-32 Current Lim Ctrl, Filter Time
14-35 Stall Protection
14-36 Fieldweakening Function
14-4* Energy Optimizing
14-40 VT Level
14-41 AEO Minimum Magnetization
14-42 Minimum AEO Frequency
14-43 Motor Cos-Phi
14-5* Environment
14-50 RFI 1
14-51 DC Link Compensation
14-52 Fan Control
14-53 Fan Monitor
14-55 Output Filter
14-56 Capacitance Output Filter
14-57 Inductance Output Filter
14-59 Actual Number of Inverter Units
14-7* Compatibility
14-72 VLT Alarm Word
14-73 VLT Warning Word
14-74 Leg. Ext. Status Word
14-8* Options
14-80 Option Supplied by External 24VDC
14-88 Option Data Storage
14-89 Option Detection
14-9* Fault Settings
14-90 Fault Level
MG37A222
Instruction Manual
Default value
4-set-up
ExpressionLimit
All set-ups
ExpressionLimit
All set-ups
[1] On
All set-ups
[0] Off
All set-ups
[1] On
All set-ups
[0] No function
All set-ups
ExpressionLimit
All set-ups
[0] Trip
All set-ups
1 N/A
All set-ups
60 s
All set-ups
ExpressionLimit
All set-ups
100 %
All set-ups
[0] Manual reset
All set-ups
ExpressionLimit
All set-ups
[0] Normal operation
All set-ups
ExpressionLimit
2 set-ups
60 s
All set-ups
60 s
All set-ups
ExpressionLimit
All set-ups
[0] No action
All set-ups
0 N/A
All set-ups
100 %
All set-ups
ExpressionLimit
All set-ups
ExpressionLimit
All set-ups
[1] Enabled
All set-ups
[0] Auto
All set-ups
66 %
All set-ups
ExpressionLimit
All set-ups
ExpressionLimit
All set-ups
ExpressionLimit
All set-ups
[1] On
1 set-up
ExpressionLimit
All set-ups
[0] Auto
All set-ups
[1] Warning
All set-ups
[0] No Filter
All set-ups
ExpressionLimit
All set-ups
ExpressionLimit
All set-ups
ExpressionLimit
1 set-up
0 N/A
All set-ups
0 N/A
All set-ups
0 N/A
All set-ups
[1] Yes
2 set-ups
0 N/A
2 set-ups
[0] Protect Option Config.
1 set-up
ExpressionLimit
1 set-up
