Programming
Par. Parameter description
No. #
33-65 Terminal X59/3 Digital Output
33-66 Terminal X59/4 Digital Output
33-67 Terminal X59/5 Digital Output
33-68 Terminal X59/6 Digital Output
33-69 Terminal X59/7 Digital Output
33-70 Terminal X59/8 Digital Output
33-8* Global Parameters
33-80 Activated Program Number
33-81 Power-up State
33-82 Drive Status Monitoring
33-83 Behavior After Error
33-84 Behavior afterEsc.
33-85 MCO Supplied by External 24VDC
33-86 Terminal at alarm
33-87 Terminal state at alarm
33-88 Status word at alarm
33-9* MCO Port Settings
33-90 X62 MCO CAN node ID
33-91 X62 MCO CAN baud rate
33-94 X60 MCO RS485 serial termination
33-95 X60 MCO RS485 serial baud rate
MG37A222
Instruction Manual
Default value
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
[0] No function
-1 N/A
[1] Motor ON
[1] On
[0] Coast
[0] Controlled stop
[0] No
[0] Relay 1
[0] Do nothing
0 N/A
127 N/A
[20] 125 Kbps
[0] Off
[2] 9600 Baud
