Danfoss VLT AutomationDrive FC 302 Instruction Manual page 11

Introduction
1
21
20
19
13
1 Local control panel (LCP)
2 Active filter card (AFC)
3 Line power contactors
4 Soft-charge resistors
5 RFI differential mode filter
6 RFI common mode filter
7 Current transformer (CT)
8 Line power bus bars to drive output
9 AC capacitors
10 RFI
11 Lower DC capacitor bank
Figure 2.4 Frame Size E9 Filter Enclosure
MG37A222
Instruction Manual
2
18
17
16
15
14
12
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
3
4
5
6
9
10
11
12 AC capacitor current transducers
13 Heatsink fan
14 Line power terminals
15 Line power disconnect
16 Electrical fuses
17 LC inductor
18 HI inductor
19 Power card
20 Control card
21 LCP cradle
7
8
9
2 2
