7. Click Review/apply and review pending changes. To apply these changes to the system, click Apply changes or click
'X' to cancel.
Figure 76: The SNMP Add/Edit view member dialog

Defining the group access policy

The group access policy defines the access rights per group and the minimum security model and security level required to
access the group. The access options are:
• Read—Management access is read-only for the selected view. Otherwise, a user or a community associated with this
group, is able to read all MIBs except those that control SNMP itself.
• Write—Management access is write for the selected view. Otherwise, a user or a community associated with this
group, is able to write all MIBs except those that control SNMP itself.
• Notify—Sends only notifications with contents that is included in the SNMP view selected for notification. Otherwise,
there is no restriction on the contents of the notifications.
Group access policies are configured using the SNMP Access Control List dialog, shown below.
Figure 77: The SNMP Access Control List dialog
Define a group access policy
1. Click on the chassis and select the SNMP tab.
2. Under View-based access control, click Configure access control list. The SNMP Access Control Listdialog
displays.
3. To define a new access policy, click Add new access, or to edit an existing access policy click the
Edit access dialog displays (see the figure below).
4. Enter details for the group access policy:
• Group name—Specify the name of an existing group that will receive this access.
™ ©
SmartNA-X 1G/10G User Guide 1.4 2015 Network Critical Solutions Limited
SmartNA-X 1G/10G Modular | SNMP | 85
icon. The Add/
