196 | IPP Module Preset Matches and Transforms | SmartNA-X 1G/10G Modular
Match name
GTP-v1-L=2-IPv6
Table 21: GTPv2 over UDP
Match name
GTP-v2-UDP-IPv4
GTP-v2-UDP-IPv6
Table 22: GTPv2 over TCP
Match name
GTP-v2-TCP-IPv4
GTP-v2-TCP-IPv6
Test the TEID flag, header length is 8 bytes if 0, 12 bytes if 1.
Table 23: GTPv2 TEID flag over UDP
Match name
GTP-v2-L=2-UDP-IPv4
GTP-v2-L=2-UDP-IPv6
Table 24: GTPv2 TEID flag over TCP
Match name
GTP-v2-L=2-TCP-IPv4
GTP-v2-L=2-TCP-IPv6

IPP module preset Transforms

The following table shows the preset Transforms that are available with the IPP module.
Match definition (start bit, width, value)
501, 3, 0
Match definition (start bit, width, value)
336, 3, 2
496, 3, 2
Match definition (start bit, width, value)
432, 3, 2
592, 3, 2
Match definition (start bit, width, value)
340, 1, 0
500, 1, 0
Match definition (start bit, width, value)
436, 1, 0
596, 1, 0
™ ©
SmartNA-X 1G/10G User Guide 1.4 2015 Network Critical Solutions Limited
