140 | Command Line Reference | SmartNA-X 1G/10G Modular
Changes are only activated following a commit command.
Syntax
set lbheaders LoadBalancerGroup { LB1 | LB2 | LB3 | LB4 } { vlan | mac_src | mac_dest | ipv4_src |
ipv4_dest | ipv6_src | ipv6_dest | port_src | port_dest }
Parameters
LoadBalancerGroup Specify the Load Balancer Group for the load balance policy configuration, for example LB1.
•
• field-list Specify none, one, two or three packet header fields to use for load balancing. Prefer to select two or three
fields (separated by spaces) as this will give a more even load balancing output across the egress ports. The following
key words are permitted:
vlan VLAN field
•
• mac_src MAC source address field
• mac_dest MAC destination address field
• ipv4_src IPv4 source address field
• ipv4_dest IPv4 destination address field
ipv6_src IPv6 source address field
•
• ipv6_dest IPv6 destination address field
• port_src UDP port source field
port_dest UDP port destination field
•
The following combinations are disallowed when specifying Load Balancer Group headers:
• IPv4 source and/or destination at the same time as IPv6 source and/or destination
• MAC source and/or destination at the same time as IPv6 destination (only; IPv6 source with MAC is allowed)
Example
Set up a load balancing policy configuration for Load Balancer Group LB1 using IPv4 source and IPv4 destination fields:
CONTROLLER>set lbheaders LB1 ipv4_src ipv4_dest
CONTROLLER>show lbheaders
Use commit command to configure the switch with these.
load balance policy headers
LB1
ipv4_src
ipv4_dest
CONTROLLER>commit
Committing load balance policy headers

delete filter

Use the delete filter command to delete a filter and remove it from any maps that are using it.
Syntax
delete filter filtername
Parameters
• filtername Specify the filter name to delete. Filter names are case-sensitive. Use quotes ("") if the filter name contains
spaces.
Example
• Delete the filter named "HTTP and HTTPS packets" and commit changes to the system:
CONTROLLER>delete filter "HTTP and HTTPS packets"
CONTROLLER>commit
™ ©
SmartNA-X 1G/10G User Guide 1.4 2015 Network Critical Solutions Limited
