6. Click Review/apply and review pending changes. To apply these changes to the system, click Apply changes or click
'X' to cancel.
Figure 72: The SNMP Add community dialog for VACM

Creating SNMP groups

SNMPv3 provides for a way to control which events authorized and authenticated users can see and perform by
associating each user with a group. A group is a label for a logical entity (combination of attributes). A group is
operational only when it is associated with an SNMP user or an SNMP community. A group also has an attribute that tells
if members should have read, write, and/or notify privileges for the view.
From the web UI, groups are configured using the SNMP Groups dialog, shown below.
Figure 73: The SNMP Groups dialog
Create an SNMP group
1. Click on the chassis and select the SNMP tab.
2. Under View-based access control, click Configure groups. The SNMP Groups dialog displays.
3. To define a new group, click Add new group, or to edit an existing community click the
Add/Edit group member dialog displays (see the figure below).
4. Enter or edit details for the group:
Group name – Enter a name for the group. Names must start with a letter and cannot be more than 32
•
alphanumeric characters long.
• Member – Member to add to the group (only one user can be added at a time). The member may be an existing
local SNMP user or a security name assigned to an existing VACM-enabled SNMP community. The same member
may belong to different groups with different security models. The membership will apply only when the specified
security model is used for a request.
• Security model– Enter a security model for the group: SNMPv1, SNMPv2c, or SNMPv3 USM.
5. Click Add group to finish setting up the group.
™ ©
SmartNA-X 1G/10G User Guide 1.4 2015 Network Critical Solutions Limited
SmartNA-X 1G/10G Modular | SNMP | 83
icon for that group. The
