Port mapping commands

This section provides reference information for packet mapping commands.

show maps

Use the show maps command to list details of each port map (committed and uncommitted). Details include source and
destination ports for each map, and any required and excluded filters applied to the map.
Syntax
show maps
Parameters
This command has no arguments or keywords.
Example
CONTROLLER>show maps
CONTROLLER>show maps
maps
1.
Source Ports:
1A
Destination Ports:
1B
1C
2.
Source Ports:
1B
Destination Ports:
1A
3.
Source Ports:
1B
Excluded Filters:
HTTP
Destination Ports:
3D
4.
Source Ports:
1B
Destination Ports:
3C
5.
Source Ports:
1B
Required Filters:
SMTP
Destination Ports:
1D

set map

Use the set map command to create maps and optionally apply filters to them. Maps can be created between physical
ports, and between logical load balancer groups on supported systems. When mapping ports, take care not to overload the
receiving port with excess traffic, such as when mapping a 10G port to a 1G port. In this situation, use filters to reduce the
amount of data received by the output port to 1G only. After setting maps, enter a commit command to replace the live
settings on the device with your new configuration.
™ ©
