Figure 33: Add RADIUS server dialog
3. Click Add server. The server is added to the list of RADIUS accounting servers.
Note: If you have multiple servers set up, you can organize server priority with the Arrange
dragging the servers into the required order. Servers higher up the list have higher priority than those further
down and will be contacted first.
4. Click Review/apply and review pending changes. To apply these changes to the system, click Apply changes or click
'X' to cancel.

Rebooting the system

You can reboot the device to reset all components of the system to the last saved/applied configuration. Any pending
updates will be lost unless applied prior to rebooting.
Attention: A reboot takes around 2–3 minutes. During this time you will be unable to login to the system and all
network traffic on the live ports will be stopped, including copper ports with TAP mode/failsafe enabled.

Reboot the system

1. Click on the chassis and select the Management tab.
2. From the management options, click Reboot. The Reboot dialog displays (see figure below).
3. Click Reboot. The device will now reboot. All traffic entering/leaving the device will be stopped for 2–3 minutes
while the device reboots.
Figure 34: Reboot dialog
™ ©
SmartNA-X 1G/10G User Guide 1.4 2015 Network Critical Solutions Limited
SmartNA-X 1G/10G Modular | SmartNA-X Administration | 41
