Physical and electrical specifications
Table 5: Physical specifications for the SmartNA-X
Feature
Ports
Slots
Power
Physical
Compliance
Environment
Standards and protocols
device.
™
Specifications
Management ports: 1 Ethernet, 1 serial
User definable: (copper, single-mode fiber, multi-mode fiber, SFP/SFP+ cage ports
available)
Max. 16 x 1Gb
Max. 4 x 10Gb
1 x 10G/1G module
3 x 1G module
AC: 100V-240V
DC: -42V to -63V
30W (no modules present)
Dimensions:450mm (w) x 44mm (h) x 450mm (d)
Emissions: EN55022 class A
Immunity: ESD: EN61000-4-2
Radiated: EN61000-4-3
EFT/Burst: EN61000-4-4
Surge: EN61000-4-5
Conducted: EN61000-4-6
Power frequency magnetic field: IEC 61000-4-8
Voltage dips & interruptions: IEC 61000-4-11
Harmonics: EN 61000-3-2
Flicker: EN 61000-3-3
Safety: EN60950-1; UL60950-1
RoHS compliance
Operating temperature: 0C to 40C
Operating relative humidity: 20% to 80% non-condensing
Storage relative humidity: 15% to 85% non-condensing
Storage temperature: -20C to 70C
IEEE 8023 10Base-T
IEEE 8023u 100Base-TX
IEEE 8023ab 1000Base-T
IEEE 802.3z 1000BASE-X
IEEE 802.3ae 10GBASE-X
™ ©
