118 | Command Line Reference | SmartNA-X 1G/10G Modular
autolock : on
lock : on
description: Web router downstream port
usage : network
port type : Registered Jack 45 (RJ45)
PORT UP
traffic threshold low : 0
traffic threshold high: 100

set port mastering

(Copper ports only) Use the set port mastering command to set the port mastery mode for a copper port.
Port mastery refers to the master/slave relationship for clock pulses in a link pairing. In each pairing only one master
is permitted, that is, a port pairing must consist of a master and a slave. Mastery only applies when auto-negotiation is
enabled (set port autoneg auto).
Syntax
set port port-id mastering { forcemaster | prefermaster | forceslave | preferslave }
Parameters
• port-id Specify the port letter to set or show. A–D for front ports; 0 or 1 for rear ports.
Forcemaster Force the port to be synchronization master (link partner must be slave).
•
• Forceslave Force the port to be synchronization slave (link partner must be master).
Prefermaster Prefer the port to be synchronization master.
•
• Preferslave Prefer the port to be synchronization slave.
Example
Set port 3A to Preferslave:
CONTROLLER>select slot 3
SLOT3>set port A mastering forcemaster
speed : set auto actual 1G
duplex : set auto actual full
mdi : set mdi-x actual mdi-x
mastering : set preferslave actual preferslave
autoneg : auto
tap : off
autolock : on
lock : off
description: Web router downstream port
usage : network
port type : Registered Jack 45 (RJ45)
PORT UP
traffic threshold low : 0
traffic threshold high: 100

set port mdi

(Copper ports only) Use the set port mdi command to specify the MDI/MDI-X (cable crossover) mode for a copper port.
Selecting auto enables the port to automatically set MDI crossover correctly.
Syntax
set port portID mdi { Auto | MDI | MDI-X }
Parameters
port-id Specify the port letter to set or show. A–D for front ports; 0 or 1 for rear ports.
•
• Auto Set auto to allow the port to set MDI crossover correctly.
MDI Set MDI (normal) mode.
•
™ ©
