7 Single II as Telephone

The Single II is a Call Recorder aimed at the automatic recording of
telephone conversations. The Single II can be connected to any regular
analogue telephone line and to the handset of a digital telephone. It is
meant to automatically record telephone calls. Telephone calls are
recorded on Flash disk or Drive during the call. After the calls have
ended the recordings can be copied to SD.
The Single II can also be used as telephone. With either a handset, a
headset or as speakerphone. In Settings the Single II must be configured
to Record from Line. (See §12.1)
NOTE: To use The Single II as Telephone it must be connected to NOTE
NOTE NOTE
the Line and not the Handset.
The Single II has a standard headset interface to which a headset can be
connected.
Recordings can be encrypted using the CryptoCard option. Encrypted
recordings can only be played using the same or a matching card to the
card the recording was made with. The use of the telephone can be
disabled if there is no CryptoCard inserted.

7.1 Headset / Speakerphone

A headset can be connected to the Single II. When the headset is used
the Hook control function key can be used for On and Off hook.
The Single II features a hook-control function key
speakerphone. Both the hook-control and the speakerphone key control
Hook contact.
NOTE: The hook-control function key takes precedence over the NOTE NOTE NOTE
speakerphone. If the hook-control function is 'Off hook', press the
Speakerphone key
display will show "Speakerphone ON". Press the speakerphone key
again to transfer the call back to the hook-control function key. The
display will show "Speakerphone OFF". If the call is on speakerphone
and the handset is off the hook then pressing the hook-control
function key will end the call.
Manual Call Recorder Single II © 2011-2014 Vidicode®
to transfer the call to the speakerphone. The
and
33
