PrimeLab Desktop Assistant
First connection of PrimeLab with PC (pairing)
The advantage of using the Bluetooth connectivity between PrimeLab and your PC
is that the two devices only need to "pair" once.
This is the same procedure as between your mobile phone and your car.
Once the connection has been established no intervention is necessary at later
connections. The devices will connect automatically and instantly.
The following steps describe the initial (and only) "pairing" of the two devices:
1) Make sure your PrimeLab is switched on and the
®
Bluetooth module is activated.
This is indicated by the "BLUE" in white on black is displayed
on the top right margin of the display. If this is not the case
follow the instructions on page "SET-1"
3) In the next window (Fig. 2)
all device are listed that may
be connected to your PC.
There must also be a device
with a Bluetooth icon and the
name "PrimeLab" (first
"Other", than, after a while
"PrimeLab") followed by
numbers (serial number). If
this is not visible, then either
your PrimeLab is switched off
or the Bluetooth transmitter
in the device is not activated
(see above).
Continued...
PDA-2
Fig. 1
®
®
®
2) Right click on the Bluetooth symbol
next to the system clock in the task bar
(Fig. 1) and select "Add Bluetooth
device".
If you cannot see a Bluetooth symbol in
the task bar click on the Bluetooth
symbol in the Windows Control Panel. If
there is no Bluetooth symbol available
there either, the Bluetooth dongle has not
been installed on your system. Check
page PDA-1 for information on how to
®
install Bluetooth on your system.
activated
deactivated
®
®
®
®
®
®
Fig. 2
