CDM-625 Advanced Satellite Modem
Preface
Additionally, the CDM-625 has been shown to comply with the following standards:
To ensure that the Modem continues to comply with these standards,
observe the following instructions:
IMPORTANT
• Connections to the transmit and receive IF ports (BNC female connectors) should be
made using a good quality coaxial cable - for example RG58/U (50Ω or RG59/U (75Ω).
• All 'D' type connectors attached to the rear panel must have back-shells that provide
continuous metallic shielding. Cable with a continuous outer shield (either foil or braid,
or both) must be used, and the shield must be bonded to the back-shell.
• The equipment must be operated with its cover on at all times. If it becomes necessary to
remove the cover, the user should ensure that the cover is correctly re-fitted before
normal operation commences.
EN 61000-3-2
EN 61000-3-3
EN 61000-4-2
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
EN 61000-4-9
EN 61000-4-11
EN 61000-4-13
Harmonic Currents Emission
Voltage Fluctuations and Flicker
ESD Immunity
EFT Burst Immunity
Surge Immunity
RF Conducted Immunity
Power frequency Magnetic Field Immunity
Pulse Magnetic Field Immunity
Voltage Dips, Interruptions, and Variations Immunity
Immunity to Harmonics
xxi
MN-0000036 (Ref MN/CDM625.IOM)
Revision 1
