CDM-625 Advanced Satellite Modem
Rear Panel Connector Pinouts

3.3.2.3 Quad E1 Operation via the Balanced G.703 / Aux G.703 Connectors

For Quad E1 operation, the optional CA-0000163 and CA-0000164 Adapter Cables, shown in Figure
3-3 and Figure 3-4 respectively, may be purchased from Comtech EF Data to adapt the Balanced
G.703 or Auxiliary G.703 9-pin Type 'D' female connectors to either a standard 15-pin Type 'D' or a
RJ-48 female connection pair. Refer to Table 3-6 or Table 3-7 for the pin assignment for these
optional adapter cables.
3.3.2.3.1

CA-0000163 Adapter Cable

Figure 3-3. CA-0000163 Adapter Cable (DB-9M

Table 3-6. CA-0000163 Pin Assignments

Twisted
P1 J1 J2
Pair
5 9
X
1
9
11
4
X
3
8
9
7
X
1
2
11
6
X
3
1
2 2
3
3–8
MN-0000036 (Ref MN/CDM625.IOM)
(2X) DB-15F)
Signal Function
Port 1 or 3 Tx In +
Port 1 or 3 Tx In -
Port 1 or 3 Rx In +
Port 1 or 3 Rx In -
Port 2 or 4 Tx In +
Port 2 of 4 Tx In -
Port 2 or 4 Rx In +
Port 2 or 4 Rx In -
-
GND
