CDM-625 Advanced Satellite Modem
Remote Control
Command
Parameter
Number of
(Instruction
Type
Arguments
& Qualifier)
AUPC
APP=
6 bytes
Parameters
Remote
N/A
4 bytes
Eb/No
Tx Power
N/A
3 bytes
Level
Increase
Tx Clock
TCK=
1 byte, value of
Source
0 thru 3
Tx Data
TCI=
1 byte, value 0
Clock Invert
or 1
Description of Arguments
Command or Query.
Defines AUPC operating parameters. Has the form abc.cd, where:
a=Defines action on max. power condition.
(0=do nothing, 1=generate Tx alarm)
b=Defines action on remote demod unlock.
(0=go to nominal power, 1=go to max power)
c.c=target Eb/No value, for remote demod, from 0.0 to 14.9 dB,
where numbers above 9.9 use hex representation for the 1 st
character, ie 14.9 is coded as E.9.
d =Max increase in Tx Power permitted, from
0.0 to 9.0 dB
Example: APP=015.67 (Sets no alarm, max power, 5.6 dB target
and 7 dB power increase.
Query only.
Returns the value of Eb/No of the remote demod.
Responds 99.9 = remote demod unlocked.
Responds xx.x if EDMAC is disabled.
xx.x=02.0 to 16.0
Example: REB=12.4
Note: For values > 16.0 dB, the reply will be 16.0
Query only.
Returns the increase in Tx power level, in dB (from the nominal
setting) due to the action of AUPC.
Responds x.x if AUPC is disabled.
Example: PLI=2.3
Command or Query.
Tx Clock Source, where:
0=Internal
1=Tx Terrestrial
2=Rx Loop-Timed
3=Ext TT (ST=RxSat)
Example: TCK=0 (selects Internal)
Command or Query
Invert Transmit Data Clock, where x may be:
0=Normal
1=Inverted
D–13
Revision 1
MN-0000036 (Ref MN/CDM625.IOM)
Query
Response to
(Instruction
Response to Query
Command
& Qualifier)
APP=
APP?
APP=abc.cd
APP?
(see description of
arguments)
APP*
APP#
N/A
REB?
REB=xx.x
(see description of
arguments)
N/A
PLI?
PLI=x.x
(see description of
arguments)
TCK=
TCK?
TCK=x
TCK?
(see description of
arguments)
TCK*
TCK#
TCI=
TCI?
TCI=x
TCI?
(see description of
TCI*
arguments)
TCI#
