E.2.1 Connector Pinout
The LAN interface is comprised of four IEEE 802.3ab 10/100/1000 BaseT copper interfaces via four
female RJ-45 connectors wired as shown in Table E-1.
Pin #
Appendix E

Table E-1. LAN Interface Connector Pinout (Typical)

1
2
3
4
5
6
7
8
Description
BI_DA+
BI_DA-
BI_DB+
BI_DC+
BI_DC-
BI_DB-
BI_DD+
BI_DD-
E–4
SLM-5650A Satellite Modem
Revision 10
Direction
Bidirectional
MN-SLM-5650A
