Controller-to-Target
Instruction Code and
Qualifier
Parameter
Type
Command Query
Global
Configuration
(cont.)
Serial Remote Control
Arguments
for Command
(Note that all arguments are ASCII numeric codes from 48 to 57)
or Query
a = CnC Mode ..............................................................same as CNM
bbbbbb = CnC Mode .................................................... same as CSD
k = expansion byte
l = Tx FEC Type ............................................................. same as TFT
m = Tx Modulation Type ............................................... same as TMD
n = Tx Code Rate ......................................................... same as TCR
oooooo.ooo = Tx Data Rate ......................................... same as TDR
pppp.pppp = Tx Frequency ............................................same as TFQ
q = Tx Framing Mode ................................................... same as TFM
c = NP Working Mode ...................................................same as GBM
r = expansion byte
e = NP Secure Mode ..................................................... same as MIS
s = Tx Reed-Solomon state ...........................................same as TRS
t = Tx Reed-Solomon code word ..................................same as TCW
u = Tx Reed-Solomon interleaver depth ....................... same as TRD
v = Tx Spectrum Invert ................................................... same as TSI
w = Tx Scrambler ...........................................................same as TSC
x = Tx Differential Encoder ............................................same as TDE
yyy.y = Tx Power Level .................................................. same as TPL
z = Tx Clock Source ......................................................same as TCK
A = Tx SCT Reference ..................................................same as SCT
B = Tx Clock Invert ......................................................... same as TCI
C = Tx Data Invert .......................................................... same as TDI
D = Tx Data Fault .......................................................... same as TDF
E = Tx BPSK Data Ordering ......................................... same as TBO
F = Tx Carrier State ...................................................... same as TXO
G = Tx Ternary Code ..................................................... same as TTC
HH = expansion bytes
ff.fff = CnC Freq Offset Range ...................................... same as CCF
I = Rx FEC Type ............................................................ same as RFT
Description of Arguments
10–48
SLM-5650A Satellite Modem
Revision 10
Target-to-Controller
Response to Query
Response to
(see Description of
Command
Arguments)
