D.4.3.2 LVDS Interface Module Installation Procedure

Insert the Interface Module straight into the slot, using the chassis' internal card guides, until it plugs

securely into the internal card receptacle.

Secure the module to the chassis using the (two) captive screws.

Connect all cable (DB-25) to the Interface Module.

Turn on the power to the modem.

SLM-5650A Satellite Modem

MN-SLM-5650A
