5. Connect to the SUN Unix server using the direct command.
[SLC]> connect direct deviceport 2
SunOS 5.7
login: frank
Password:
Last login: Wed Jul 14 16:07:49 from computer
Sun Microsystems Inc.SunOS 5.7Generic October 1998
SunOS computer 5.7 Generic_123485-05 sun4m sparc SUNW,SPARCstation-20
$
6. Use the escape sequence to escape from direct mode back to the command line interface.

Local Serial Connection to Network Device via Telnet

This example shows a terminal device connected to an SLC device port, and a Sun server
connected over the network to the SLC device. When a connection is established between the
device port and an outbound Telnet session, users can access the Sun server as though they
were directly connected to it. (See
SLC 8000 Advanced Console Manager
Serial Cable
to Device Port 2
In this example, the sysadmin would:
1. Display the current settings for device port 2:
[SLC]> show deviceport port 2
___Current Device Port
Settings________________________________________________
Number: 2 Name: Port-2
Modem Settings-------------Data Settings-----------IP Settings-------
Modem State: disabled
Modem Mode: text
Timeout Logins: disabled
Local IP: negotiate
Remote IP: negotiate
Authentication: PAP
CHAP Host: <none>
CHAP Secret: <none>
NAT: disabled
Dial-out Login: <none>
Dial-out Password: <none>
Dial-out Number: <none>
Dial-back Number: usernumber
Initialization Script: <none>
SLC™ 8000 Advanced Console Manager User Guide
Chapter 11: Connections on page

Figure 14-4 Local Serial Connection to Network Device via Telnet

Baud Rate: 9600
Data Bits: 8
Stop Bits: 1
Parity: none
Flow Control: xon/xoff
Logins: disabled
Break Sequence: \x1bB
Check DSR: disabled
Close DSR: disabled
209).
Internet
Telnet: disabled
Telnet Port: 2002
SSH: disabled
SSH Port: 3002
IP: <none>
14: Application Examples
Sun UNIX Server
