10: Remote Power Managers

The SLC supports managing remote power managers (RPMs) for devices from over 140 vendors.
The RPMs can be either PDUs or UPSes, and can be managed via SNMP, serial port, network
and USB connections. The RPMs web page displays a list of all currently managed RPMs with an
overview of their current status, with options to control and view detailed status for each RPM,
depending on its supported capabilities.
Network and SNMP managed RPMs are disabled in FIPS mode. The only action that can be
performed on a network or SNMP managed RPM in FIPS mode is that it can be deleted via the
CLI.
For notes on optimizing the management of specific devices, see
Optimizing and Troubleshooting RPM Behavior (on page

Devices - RPMs

To control or view status for an RPM:
1. Click the Devices tab and select the RPMs option. The RPMs page displays.
2. In the lower section of the page, select an RPM by clicking on the radio button to the far right
in the RPM's row. The options that are available for that RPM will be available (ungreyed).
Select one of the following options:
Refresh
Add Device
Shutdown Order
SLC™ 8000 Advanced Console Manager User Guide
Figure 10-1 Devices > RPMs
Refreshes the information in the RPMs table.
Displays the Device Ports > RPMs - Add Device
managed PDU or UPS.
Displays the order in which all UPS devices are shutdown in the event
that a UPS reaches a low battery state. See
information, see RPM Shutdown
205).
to add a new
Figure 10-2. For more
Procedure.
193
