3. Enter the following:
Power Management
Sequence
RPM
SLC™ 8000 Advanced Console Manager User Guide

Figure 8-6 Device Ports - Power Management

A series of one to ten characters that will display the Power Management menu
when connected to the device port. The default value is Esc+P (escape key, then
uppercase "P"). This value is specified as
character 27 ( ) followed by a
1B
See Key Sequences on page 183
behavior.
For each managed power supply, select a RPM, most likely a PDU, which has
outlets that can be individually controlled, and which provides power to the device
connected to the device port.
, which is hexidecimal (
\x1bP
.
P
for notes on key sequence precedence and
8: Device Ports
)
\x
134
