Figure 10-2 Rpm Shutdown Order - Lantronix SLC 8000 User Manual

Notifications
Raw Data
Logs
Environmental
Managed Device
Outlets
Beeper: Enable, Mute,
Disable
Reboot
Shutdown
Delete
SLC™ 8000 Advanced Console Manager User Guide
Displays the notifications configured for each PDU and UPS. See
Figure 10-3.
Displays a window with all of the information returned by the driver
when a query for status is requested. This option is available for all
RPMs. See Figure 10-4.
Displays a window with any logging information that has been
accumulated for the selected RPM, if logging is enabled for the RPM.
This option is available for all RPMs. See
Displays a window with any environmental (humidity and
temperature) information that may be available for the selected RPM,
if sensors are installed for the RPM. This option is available for all
RPMs. See Figure 10-6.
Displays the RPMs - Manage Device
and configuration for the selected RPM. This option is available for all
RPMs.
Displays the RPMs - Outlets
outlet control and status.
If the RPM has a beeper than can be controlled, these options allow
the administrator to Enable, Mute, or Disable the beeper. If you try to
use Mute to silence a beeper and the beeper continues to sound, the
UPS most likely does not support mute, and the Disable option will be
the only way to silence the beeper.
Reboots the RPM immediately, which may interrupt the power
provided by the RPM while it is rebooting. Some PDUs and UPSes
have a default delay that they will wait before initiating a reboot; this
setting may be visible in the raw data (see above) as
"ups.delay.reboot".
Shutsdown the RPM immediately, which will interrupt the power
provided by the RPM. Some PDUs and UPSes have a default delay
that they will wait before initiating a shutdown; this setting may be
visible in the raw data (see above) as "ups.delay.shutdown".
Deletes the selected RPM, after a confirmation.

Figure 10-2 RPM Shutdown Order

10: Remote Power Managers
Figure 10-5.
page, with the complete status
page for RPMs that support individual
