SM24TBT4XPA Quick Start Guide
!
Thank you for choosing Lantronix. Please register the SM24TBT4XPA in order to receive notifications
for firmware and documentation updates at
What's In The Box
Quick Start
START
1. Hardware Overview
2. Install SM24TBT4XPA Hardware
Prepare to Install
1. Unbox and verify the contents.
2. Review and follow the safety information in the Install Guide.
3. Ensure that the computer used to access the SM24TBT4XPA web UI has an Ethernet port and Internet
access, a recent Web browser and/or a terminal emulator running, and an RJ-11 port
Install SM24TBT4XPA Hardware
1. Desktop: Place the provided 4 Rubber feet on bottom of SM24TBT4XPA .
2. 19" Rack: Use the 2 Rack Mount Ears and screws to mount the SM24TBT4XPA .
www.lantronix.com/product-registration.
SM24TBT4XPA
SM24TBT4XPA
SM24TBT4XPA Front Panel
SM24TBT4XPA Back Panel
Accessories
AC Power Cord (-NA)
RJ45 to DB9F Adapter
Two Rack Mount Ears
Four Rubber feet
Console Port cable
Postcard
Part Number
3344
6WPDB92RJ453
6EFS226C0E09
6RR2005AB4B2
6WPDB92RJ453
7MPLANTRNX02
