Remote Access Server; Reverse Terminal Server; Figure 11-1 Terminal Server; Figure 11-2 Remote Access Server - Lantronix SLC 8000 User Manual

VT100 Terminals

Remote Access Server

In this setup, the SLC 8000 advanced console manager is connected to one or more modems by
its device ports. Configure the device ports on the
the Dial-in option in the Modem Settings section. Most customers use the modems in PPP mode
to establish an IP connection to the SLC unit and either Telnet or SSH into the SLC 8000
advanced console manager. They could also select text mode where, using a terminal emulation
program, a user could dial into the SLC unit and connect to the command line interface.
Phone System

Reverse Terminal Server

In this scenario, the SLC 8000 advanced console manager has one or more device ports
connected to one or more serial ports of a mainframe server. Users can access a terminal session
by establishing a Telnet or SSH session to the SLC unit. To configure the SLC console manager,
select the Enable Telnet In or Enable SSH In option on the
SLC™ 8000 Advanced Console Manager User Guide

Figure 11-1 Terminal Server

SLC 8000 Advanced Console Manager
Serial
Connections

Figure 11-2 Remote Access Server

SLC 8000 Advanced Console Manager
Serial
Modems
Connections

Figure 11-3 Reverse Terminal Server

Unix Server
Serial
Sessions
Telnet Sessions (via
Network connection)
Device Ports > Settings
Device Ports > Settings
SLC 8000 Advanced Console Manager
11: Connections
Server
web page by selecting
Internal
Network
Network
Connections
page.
PC
PC
Telnet/SSH
PC
Sessions
