Lantronix SLC 8000 User Manual page 132

DOD CHAP Handshake
Enable NAT
Dial-out Number
Remote/Dial-out Login
Remote/Dial-out
Password
Retype
Restart Delay
CBCP Server Allow
No Callback
CBCP Client Type
3. To save settings for just this port, click the Apply button.
4. To save selected settings to ports other than the one you are configuring:
- From the Apply Settings drop-down box, select none, a group of settings, or All.
- In to Device Ports, type the device port numbers, separated by commas; indicate a range
of port numbers with a hyphen (e.g., 2, 5, 7-10).
Note: It may take a few minutes for the system to apply the settings to multiple ports.
SLC™ 8000 Advanced Console Manager User Guide
For DOD Authentication, enter the Host/User Name for UNIX systems) or
Secret/User Password (for Windows systems) used for CHAP authentication.
May have up to 128 characters.
Select to enable Network Address Translation (NAT) for dial-in and dial-out
PPP connections on a per modem (device port or USB port) basis. Users
dialing into the SLC 8000 advanced console manager access the network
connected to Eth1 and/or Eth2.
Note: IP forwarding must be enabled on the
for NAT to work. See Chapter 6: Basic Parameters on page
Phone number for dialing out to a remote system or serial device. May have up
to 20 characters. Any format is acceptable.
User ID for dialing out to a remote system. May have up to 32 characters.
Password for dialing out to a remote system. May have up to 64 characters.
Re-enter remote/dial-out password for dialing out to a remote system. May
have up to 64 characters.
The number of seconds after the timeout and before the SLC unit attempts
another connection. The default is 30 seconds.
For CBCP Server state, allows "No Callback" as an option in the CBCP
handshake in addition to User-defined Number and Admin-defined Number.
For CBCP Client, this selects the number that the client would like to use for
callback - either a user-defined number passed to the server (specified by the
Fixed Dial-back Number) or an administrator-defined number determined by
the server based on the login that is PAP or CHAP authenticated.
8: Device Ports
Network > Network Settings
66.
