Host And Login For Export - Lantronix SLC 8000 User Manual

Key Name
Key Type
Number of Bits
Passphrase / Retype
Passphrase
SECSH Format
Public Key Filename

Host and Login for Export

Export via
Host
Path
Login
Password /
Retype Password
To view or delete a key:
1. Select the key from the appropriate table. The View and Delete buttons become active.
2. To view the key, click the View button. A pop-up page displays the key.
Imported key for sysadmin@DaveSLM:
ssh-rsa AAAAB3NzaC1yc2EAAAABIwAAAIEAxGxPGY9HsG9VqroDo98B89Cf
haqB6jG//0tTMKkb3zrpPu0HHAXaiVXHAvv7lAte31VTpoXdLAXN0uCvuJLf
aL/LvvGmoEWBuBSu505lQHfL70ijxZWOEVTJGFqUQTSq8Ls3/v3lkUJEX5ln
2AlQx0F40I5wNEC0+m3d5QE+FKc= sysadmin@DaveSLM
3. To delete the key, click the Delete button.
To view, reset, or import SSH RSA1, RSA, And DSA host keys:
1. On the User Authentication - SSH Keys page, click the SSH Server/Host Keys link at the
top right. The following page displays the current host keys. In the example below, the current
keys are the defaults.
SLC™ 8000 Advanced Console Manager User Guide
Name of the key. This will generate the public key filename (e.g., <keyname>.pub).
Select either the RSA or the DSA encryption standard. RSA is the default.
Select the number of bits in the key (1024, 2048, 3072, or 4096). The default is
2048.
Optionally, enter a passphrase associated with the key. The passphrase may have
up to 50 characters. The passphrase is an optional password that can be
associated with an SSH key. It is unique to each user and to each key.
See Key Sequences for notes on key sequence precedence and behavior.
Indicate whether the keys will be exported in SECSH format (by default the key is
exported in OpenSSH format).
Filename of the public host key.
Select the method (SCP, SFTP, FTP, HTTPS, or Copy/Paste) of exporting the key
to the remote server. Copy/Paste, the default, requires no other parameters for
export.
IP address of the remote server to which the SLC 8000 advanced console manager
will SCP, SFTP or FTP the public key file.
Optional path of the file on the host to SCP, SFTP or FTP the public key too.
User ID to use to SCP, SFTP or FTP the public key file.
Password to use to SCP, SFTP or FTP the public key file.
12: User Authentication
260
