Device Ports

On the Devices > Device Ports
ports, view a summary of current port modes, establish the maximum number of direct
connections for each device port, and select individual ports to configure.
1. Click the Devices tab and select the Device Ports option. The following page displays:
Current port numbering schemes for Telnet, SSH, and TCP ports display on the left. The list of
ports 1-16 on the right includes the individual ports and their current mode.
Note: For units with more ports, click the buttons above the table to view additional
ports.
Icons that represent some of the possible modes include:
Idle The port is not in use.
The port is in data/text mode.
Note:
Settings (on page
An external modem is connected to the port. The user may dial into or out of the port.
Telnet in or SSH in is enabled for the device port. The device port is either waiting for a Telnet
or SSH login or has received a Telnet or SSH login (a user has logged in).
SLC™ 8000 Advanced Console Manager User Guide
page, you can set up the numbering of Telnet, SSH, and TCP
Figure 8-3 Devices > Device Ports
You may set up ports to allow Telnet access using the IP Setting per
123).
8: Device Ports
Device Ports -
121
