12.6 Wiring for S0 meter

The SO connection for external power meters is connected to a 6-pin S0-Out/In connection (S0-OUT and
S0-IN)) or to 4-pin S0-IN as follows:
SO meters in general
S0
Solar-Log™
PIN
1
2
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
The maximum cable length between the power meter and Solar-Log™ is 10 meters.
Wiring for Inepro 75D meter via S0
Article Number: 255420
Inepro 75D
S0
Solar-Log™
PIN
1
2
3
4
Place a cable bridge between pin 3 and 4 on the Solar-Log™.
Power meter
Assignment
S0+
S0-
Power meter
Assignment
Pin 6 - S0+
Pin 5 - S0-
Connecting accessories
