Configuration Menu
Note!
Switch states / Color Definition
The switching state of each contact is displayed with the following symbols:
Symbol
The current switching states are display within a few second and are continuously updated.
142
Click on this symbol to display all of the hardware data that can be accessed and
recorded by the Solar-Log™ and to display the target state.
Explanation Text Notes
Target state: On If the hardware does not support the current state being read, this
Actual state: On symbol is also used to clearly identify a fault case.
Everything OK
Target state: Off If the hardware does not support the current state being read, this
Actual state: Off symbol is also used to clearly identify a fault case.
Everything OK
Target state: On For example: The Solar-Log™ determined that the switch should be
Actual state: Off activated (e.g. surplus reached), but the command was not sent to
the switch. This can only happen when the switching state can be
read.
=> This state is temporarily valid, but not a longer period without a
change.
(e.g. the switch does not accept the switching command.)
Target state: Off For example: The Solar-Log™ determined that the switch should be
Actual state: On deactivated (e.g. surplus too low), but the command was not sent
to the switch. This can only happen when the switching state can be
read.
=> This state is temporarily valid, but not a longer period without a
change.
(e.g. the switch does not accept the switching command.)
Switch state: None The switch is not assigned to a group.
Actual state: Unknown => No target state
The switch state cannot be read or the switch is not available.
=> If no state can be read (hardware does not support this), ever-
ything is ok.
=> Otherwise the hardware is not available (fault).
Target state: On The switch state can be read, but the hardware is unavailable.
Actual state: Unknown
Error
Target state: Off The switch state can be read, but the hardware is unavailable.
Actual state: Unknown
Error
Target state: None The switch can be read, but the switch is not assigned to a group.
Actual state: On => No target state
Everything OK
Target state: None The switch can be read, but the switch is not assigned to a group.
Actual state: Off => No target state
Everything OK
