Solar-Log 200 Manual page 238

Accessing Yield Data
•
Year
:
displays the Year Graph View as a bar graph. There are two tabs in the Year View, the same as in the
Month View:
The Consumption Overview
The total consumption values are displayed in the Consumption Overview as a bar graph.
Sub-consumer Overview
In the
consumption displayed in different colors. Below this, the values are also displayed in a pie chart with the
colors in the key.
There is the option from both views to select the individual months directly from the individual bars
and sections.
•
Total :
displays the Total Graph View as a bar graph. There are two tabs in the Total View, the same as in the
Year View:
Consumption Overview
The
The total consumption values are displayed in the Consumption Overview as a bar graph.
In the Sub-consumer Overview
consumption displayed in different colors. Below this, the values are also displayed in a pie chart with the
colors in the key.
There is the option from both views to select the individual years directly from the individual bars and
sections.
238
and the Sub-consumer Overview
, you see the devices connected as a bar graph with the power
Sub-consumer Overview
and the
, you see the devices connected as a bar graph with the power
.
.
