Unit connections
Bottom connections

Fig.: Bottom connections Solar-Log 300

Solar-Log 300 / Solar-Log 250
RS485/422 - B
Power 12 V
Network
20
RS485 interface, 6 pin:
Connection for inverters
and additional accessories
12 volt DC input
Ethernet network interface,
10/100 Mbit
