Connecting accessories
10�6 Wiring for S0 meter
The SO connection for external power meters is connected to a 6-pin S0
S0 as follows:
B
SO meters in general
S0 or S0
A B
Solar-Log™
PIN
1
2
3
4
The maximum cable length between the power meter and Solar-Log™ is 10 meters.
Wiring Inepro 75D meter via S0
Article Number: 255420
Inepro 75D
S0 or S0
A B
Solar-Log™
PIN
1
2
3
4
44
Power meter
Assignment
S0+
S0-
Connecting a bridge be-
tween pins 3 and 4.
and S0
A B
Power meter
Assignment
Pin 6 - S0+
Pin 5 - S0-
Connecting a bridge be-
tween pins 3 and 4.
-In/Out connection or 4-pin
A
