Accessing Diagnostic values
Type of Reduction:
This contains the current type of power reduction that is specified by the control source.
Displayed Text
PMF_NONE
PMF_PR_ERROR
PMF_PR_FIX_PERC
PMF_PR_FIX_KW
PMF_PR_VAR_PERC
PMF_PR_VAR_KW
PMF_PR_FIX_MATRIX
PMF_PR_VAR_MATRIX
Value specification from:
This field indications how the control value used was determined.
Displayed Text
PMV_NONE
PMV_CONFIG
PMV_MODE
PMV_PR_PIGGY
PMV_MPR_PIGGY
PMV_MODBUS_1
PMV_MODBUS_2
PMV_PROFILE_ADAM
PMV_PROFILE_INTERN
PMV_ERROR
PMV_CONFIG_UTILITY
PMV_MODBUS_DM
204
Explanation
Text
No power reduction function.
An error occurred while determining the power reduction func-
tion.
Fixed reduction at % DC.
Fixed reduction at X kW (AC)
Fixed reduction at % DC with self-consumption calculation.
Fixed reduction at X kW (AC) with self-consumption calculation.
Reduction based on the value from the matrix (ripple control
receiver configuration).
Reduction based on the value from the matrix (ripple control
receiver configuration) with self-consumption calculation.
Explanation
Text
No control source.
The value is stored in the configuration.
The value can be determined by the reduction mode.
The value comes from the PM (power reduction) input
(and is determined in combination with the matrix in the confi-
guration or PM profile).
The value comes from the PM (power reduction) input of the
master (and is determined in combination with the matrix in the
configuration or PM profile).
The value comes from the ModBus PM V1 interface.
The value comes from the ModBus PM V2 interface.
The value comes from the analog or digital input of the IO Box
(Adam Box).
The value is specified in the PM profile.
An error occurred while determining the value.
The value was determined via the internal configuration based
the Utility Meter measurement.
The value comes from the ModBus DM interface (direct seller
interface).
