Solar-Log PRO2 Quick Start Manual

Changing the Modbus address by using the touch panel keys on the meter
The Modbus address can be changed from the Program Menu (see supplementary sheet) under "PRO – 2."
Additional changes are possible. A password is required to access the sub-menu "PRO – 3." The default
password is "0000" – it can be changed via the programming.
Attention
Measurement for billing purpose only with MIDconfirmed meters.
Example for MID-labeling:
For further requests regarding Solar-Log™, or meter configuration inside Solar-Log™ please consider:
info@solar-log.com
or: +49 (0)7428/4089-300
For further requests regarding the PRO meter please consider:
info@kdk-dornscheidt.com
or: 02244 / 919940
Solar-Log GmbH • www.solar-log.com • Subject to change without notice • EN | 06.2021 | Version 1.3
M 18
0122
Quick Start Guide
Solar-Log™ PRO2
Electronic single-phase energy meter for DIN-railmount
with MID–confirmation.
Please note
This document is only a quick reference guide and does not handle every function. The complete users
guide is available at: www.kdk-dornscheidt.de
Information for your safety
This quick start guide does not contain all of the safety instructions for operating the meter. Due to special
operating conditions and/or local laws and regulations, additional measures may be required.
Trained Personnel
The meter may only be installed and connected by a trained, qualified specialist. Trained, qualified special-
ists are those who are certified to put devices, systems and circuits into operation, to switch them on, to
ground them and to mark them according to safety standards and regulations.
Attention
Case is sealed, do not open the meter! No warranty if case is opened or seal is removed.
Dimensions (mm)
Width: 35,8 mm
Height with cover: 141,5 mm
Height without cover: 92,5 mm
Depth: 63,0 mm
