Accessing Diagnostic values

17.2 Battery Diagnostic

To access the Battery diagnostic menu, go to
The following tabs can be selected from this menu:
•

Current Measurement Values

•
Charging History 1-Day
•
Charging History 7-Days
•
Balances
17.2.1 Current Measurement Values
The following values are available from the
•
Battery voltage
The current voltage of the battery.
•
Charge Level (%)
The current charge status of the battery as percentage.
(The charge level for power meters in battery meter mode is currently not set.)
•
Current charging power [W]
The battery's current amount of charge in watts.
•
Current discharging power [W]
The battery's current discharge amount in watts.

Fig.: Battery diagnosis - Current measurement values

194
Diagnostic | Battery Diagnostic.
Current Measurement Values
tab:
