Accessing Yield Data

18 Accessing Yield Data
Click on Yield Data in the tool bar to access the Yield Data menu. The following options can be selected
from the left-side navigation menu.
•

Current values

•
Production
•
Consumption (only appears when a consumption meter is connected)
•
Balances
•
Finances
•
Sensor (only appears when a sensor is connected)
•
System Information
18.1 Current values
Cockpit
The
includes the following values:

Fig.: The plant's current values (cockpit view)

•
Consumption (only when consumption meters are connected). This displays the current consump-
tion.
•
Production (power generated by the plant) + discharge *only with a connected battery system)
displays the current production and battery discharge.
•
Feed-in amount (only when meters are connected). This displays the power output that is currently
being fed into the grid.
There are two graphs located below the Dashboard display:
222
tab can be automatically selected from the
Current values
. the Dashboard view of the plant
