Chapter 3 Installing Router
common buildings, the neutral points have been buried into the ground during construction
and wiring. You must verify if the power supply of the building has been properly grounded.
Please install the power cable by performing the following steps:
Step 1
Step 2
Step 3
3.4

Connecting the Console

Ruijie
configuration.Through this interface, user can complete the local configuration of the routers.
Configuration attributes:
Connector
Interface standard
Baud rate
Supported services
To connect the console port of the router:
Connect one end of the supplied configuration cable to the console port of the router and
another to DB-9 male connector used to configure the router. Please verify that a
SuperTerminal is run on the PC.
3.5

Installing Cards

This section introdces how to install the SIC cards and NMX cards supported on RSR10/20
series.
3.5.1

Installing Line Cards

Step 1
3-6
Check the router is in the power off position. Connect one end of the supplied
power cable to the socket on the rear panel of the cabinet and another to the
AC power socket.
Turn the router to power on position.
For RSR10-02 and RSR20-04, check the STATUS indicator on the front panel
is on. If so, it means that the power cable is correctly connected.
For RSR20-14, RSR20-18 and RSR20-24, check the POWER indicator on the
front panel is on. If so, it means that the power cable is correctly connected.
series routers supply
Switch off all power supply connected to the router. Otherwise electric shock
and device damage may occur.
an EIA/TIA-232
RJ-45
Asyn EIA/TIA-232
The default is 9600bps.
1. Command line interface
2. Connection to the character terminal
Installation Manual
configuration console for local
