  • Page 1 RG-RSR30 Series Routers Hardware Installation and Reference Guide 1.02...

  • Page 2: Copyright Statement

    Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited. are registered trademarks of Ruijie Networks.

  • Page 3: Obtaining Technical Assistance

    It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance  Ruijie Networks website: http://www.ruijienetworks.com  Online customer services: http://webchat.ruijie.com.cn ...
  • Page 4 Overview Overview The RSR30 series routers are proprietary data communication products independently developed by Ruijie Networks Co. Ltd by using advanced semiconductor and communication control technologies. Ruijie series routers are developed in full compliance with international standard, therefore, they are similar to major routers in terms of usage and configuration.
  • Page 5  6-port module (NMX-6FEH)  Ruijie Ipsec NMX encrypted module (NMX-SECH V1.X) (up to six modules are supported) When purchasing the RSR30-44 modular routers, select functional modules following these rules:  Unless otherwise specified, up to four modules of the same type are supported.
  • Page 6 Hardware Installation and Reference Guide Overview The RSR30-44 adopts GB4943-compliant power supplies to prevent surging, over-voltage, under-voltage and over-current for stable, and reliable output with instant power-failure protection  Chassis The RSR30-44 adopts standard 19in chassis, which can resist electromagnetic radiation, shock, high and low temperature.

  • Page 7: Slot Numbering

    Hardware Installation and Reference Guide Overview Multiple as required (at most four NMX modules and four SIC modules can be Slot for functional module configured) Slot for power module 2 (at most two modules can be configured) External dimension (W x H 440 mm x 161.4 mm x 412 mm (excluding the hangers on both sides) x D) Input voltage...
  • Page 8 Hardware Installation and Reference Guide Overview NMX-8E1H V2.XX, NMX-4E1H V2.XX, NMX-4HSH V1.1X, NMX-24ESW V1.XX, NMX-2GEH V1.1X, NMX-1CPOSH V1.1X, NMX-1ATMH V1.XX, NMX-6FEH, NMX-SECH V1.x NMX-8E1H V2.XX, NMX-4E1H V2.XX, NMX-24ESW is not supported NMX-4HSH V1.1X, NMX-2GEH V1.1X, NMX-1CPOSH V1.1X, NMX-1ATMH V1.XX, NMX-6FEH, NMX-SECH V1.x NMX-8E1H V2.XX, NMX-4E1H V2.XX, NMX-4HSH V1.1X, NMX-24ESW V1.XX, NMX-2GEH V1.1X, NMX-1CPOSH V1.1X,...

  • Page 9: Module Attributes

    Hardware Installation and Reference Guide Overview Appearance and Indicators Appearance of the RSR30-RCM44-512M-2GE RSR30-RCM44-512M-2GE has two status indicators:  Power: indicating power status. Green and ON indicate the power module works normally; Green and off indicate the power is faulty. ...

  • Page 10: Module Interface

    Hardware Installation and Reference Guide Overview Module Interface 1000M Ethernet interface The RSR30-RCM44-512M-2GE comes with two 10/100/1000 Mbps Ethernet interfaces, each supports both optical and electric connectors-RJ45 and SFP. Users may choose them according to actual needs. The RSR30-RCM44-512M-2GE comes with four 1000 Base-FX SFP/LC pluggable optical interface modules. User may choose them according to actual needs.

  • Page 11: Module Cable

    Hardware Installation and Reference Guide Overview The module includes one SCSI DB68 connector with one RDY indicator, and eight ACT indicators. RDY indicator: ON means the sub-card is powered on and initialized. ACT indicator: Flash means data is transmitting on the port. Attributes of the SIC-8A Card The basic attributes are as below: ...

  • Page 12: Isdn Interface Card

    Hardware Installation and Reference Guide Overview The module has a status indicator (LINK) and the sub-card RDY indicator.  LINK: ON means the physical connection between the synchronous port and external devices is set up and the upper-level protocol is UP. ...
  • Page 13 Hardware Installation and Reference Guide Overview Appearance and Indicators Appearance of the 1-port ISDN U-interface card (SIC-1B-U) Appearance of the 1-port ISDN S/T U-interface card (SIC-1B-S/T) The module has the status indicator ACT and the sub-card indicator RDY. Moreover, two channel status indicators are available-B1 and B2.
  • Page 14 Hardware Installation and Reference Guide Overview EMI: GB 9254-1998 Class A EMS: GB/T 17618-1998 Module Cable SIC-1B-U and SIC-1B-S/T use standard telephone wires. No cables are shipped with the module. Users need to purchase it separately. E1 Interface Card SIC module model: ...

  • Page 15: Module Cables

    Hardware Installation and Reference Guide Overview EMS: GB/T 17618-1998 Module Cables Two kinds of cables are available: E1 balanced cable/DB9 male connector-RJ45 male connector/120Ω/3 meters: one end is DB9 male connector  and the other end is RJ45 crystal connector. E1 unbalanced cable/DB9 male connector-2*BNC/75Ω/3 meters: one end is DB9 male connector and the other ...

  • Page 16: Sic-2Fxo Interface Card

    Hardware Installation and Reference Guide Overview Module Cable The SIC-2FXS module uses standard phone wires. No cables are shipped with the module. Users need to purchase it separately. SIC-2FXO Interface Card SIC module model: SIC-2FXO Appearance and Indicators Appearance of the SIC-2FXO interface card The interface card includes the IN USE indicators for ports and one ACT indicator.
  • Page 17 Hardware Installation and Reference Guide Overview Appearance and Indicators Appearance of the SIC-3G-TD interface card Panel indicator description: Indicator Description Solid on means that firmware initialization of the line card is complete. OFF means the firmware initialization of the line card is not complete or fails. Solid on means the link is through.
  • Page 18 Hardware Installation and Reference Guide Overview When the module runs normally, the RJ-45 interface does not need to connect a cable. Module Cable The SMA interface of the SIC-3G-TD module can connect two types of antennas: pole-shaped antenna and 3m extension magnetic antenna.

  • Page 19: Installing The Sim Card

    Hardware Installation and Reference Guide Overview Specifications of 3m extension magnetic antenna (ANT-RJ3G3MA): Attribute Parameter Frequency range 824-960 MHz/1710-2170 MHz ≤ 2.5 VSWR Input impedance 50 ohms ≥ 3dBi Gain Polarization Vertical Interface type SMA-J Length 224mm Color Black Operating temperature -40℃...

  • Page 20: Sic-3G-Cdma Interface Card

    Hardware Installation and Reference Guide Overview 1. The gap of the SIM card should be aligned with that of the SIM slot. In this manner, the SIM card can be installed correctly. 2. The SIM slot should be closed when there is no SIM card in it. Otherwise, there are risks of damaging the SIM slot.
  • Page 21 Hardware Installation and Reference Guide Overview Indicator Description Solid on means the strong signal. RSSI Flashing means the medium/low signal. Off means the weak signal or no signal. Solid on means the RTT service is effective. Off means there is no RTT service. Solid on means the EV-DO service is effective.
  • Page 22 Hardware Installation and Reference Guide Overview Pole-shaped antenna specifications Attribute Parameter Frequency range 824-960 MHz/1710-2170 MHz ≤ 3 VSWR Input impedance 50 ohms 1.8 dBi (824 MHz-960 MHz) Gain 2.0 dBi (1710 MHz-2170 GHz） Polarization Linear Interface type SMA Straight Plug Reverse Length 145mm Color...
  • Page 23 Hardware Installation and Reference Guide Overview Specifications of 3m extension magnetic antenna (ANT-RJ3G3MA): Attribute Parameter Frequency range 824-960 MHz/1710-2170 MHz ≤ 2.5 VSWR Input impedance 50 ohms ≥ 3dBi Gain Polarization Vertical Interface type SMA-J Length 224mm Color Black Operating temperature -40℃...

  • Page 24: Sic-3G-Wcdma Interface Card

    Hardware Installation and Reference Guide Overview 1. The gap of the SIM card should be aligned with that of the SIM slot. In this manner, the SIM card can be installed correctly. 2. The SIM slot should be closed when there is no SIM card in it. Otherwise, there are risks of damaging the SIM slot.
  • Page 25 Hardware Installation and Reference Guide Overview Indicator Description Flashing means the data is being transmitted. Solid on means the strong signal. RSSI Flashing means the medium/low signal. Off means the weak signal or no signal. Solid on means the UMTS service is effective. UMTS Off means there is no UMTS service.
  • Page 26 Hardware Installation and Reference Guide Overview Pole-shaped antenna specifications Attribute Parameter Frequency range 824-960 MHz/1710-2170 MHz ≤ 3 VSWR Input impedance 50 ohms 1.8 dBi (824 MHz-960 MHz) Gain 2.0 dBi (1710 MHz-2170 GHz） Polarization Linear Interface type SMA Straight Plug Reverse Length 145mm Color...
  • Page 27 Hardware Installation and Reference Guide Overview Specifications of 3m extension magnetic antenna (ANT-RJ3G3MA): Attribute Parameter Frequency range 824-960 MHz/1710-2170 MHz ≤ 2.5 VSWR Input impedance 50 ohms ≥ 3dBi Gain Polarization Vertical Interface type SMA-J Length 224mm Color Black Operating temperature -40℃...
  • Page 28 Hardware Installation and Reference Guide Overview 1. The gap of the SIM card should be aligned with that of the SIM slot. In this manner, the SIM card can be installed correctly. 2. The SIM slot should be closed when there is no SIM card in it. Otherwise, there are risks of damaging the SIM slot.

  • Page 29: Module Cables

    Hardware Installation and Reference Guide Overview Attributes of the NMX-4HSH Card The basic attributes are as below:  NMX-4HSH Interface 4 SDB26POS Interface standard V.24 (DTE/DCE), V.35 (DTE/DCE) Maximum rate 115.2K (V.24) or 8.192M (V.35) Module Cables The following cables can be used: ...
  • Page 30 Hardware Installation and Reference Guide Overview The module includes the status indicator for each CE1 port and the Ready indicator for sub card. Each CE1 port has one LINK indicator.  Link indicator: ON means the link is set up, OFF not connected. ...
  • Page 31 Hardware Installation and Reference Guide Overview Attributes of the NMX-2GEH Module The NMX-2GEH module comes with 2 10/100/1000 Mbps Ethernet interfaces, each supports both optical and electric connectors-RJ45 and SFP. Users may choose them according to actual needs. The basic attributes are as below: ...

  • Page 32: Module Attributes

    Hardware Installation and Reference Guide Overview This module has the status indicator for CPOS port and the sub-card Ready indicators. Each CPOS port has two status indicators: Link and Alarm.  Link: ON means the link is set up, OFF not connected. ...
  • Page 33 Hardware Installation and Reference Guide Overview Module Cables No cables are shipped with this moudle, that is, the cables and SFP parts are sold separately. NMX-1ATM-STM1H NMX module : 1-port ATM module (NMX-1ATM-STM1H) Appearance and Indicators Appearance of 1-port ATM module (NMX-1ATM-STM1H) This module has the status indicator for ATM port and the sub-card Ready indicators.
  • Page 34 Hardware Installation and Reference Guide Overview power Minimum -20.0 dBm -15.0 dBm -5.0 dBm -5.0 dBm Maximum -14.0 dBm -8.0 dBm 0 dBm 0 dBm Receiver sensitivity -30.0 dBm -28.0 dBm -34.0 dBm -34.0 dBm Overload optical power -14.0 dBm -8.0 dBm -10.0 dBm -10.0 dBm...
  • Page 35 Hardware Installation and Reference Guide Overview Hot-plugging Not supported Module Cables Cat-5 8-core UTP cables with RJ-45 connector are used. NMX-1POS-STM1H NMX module:1-port POS module (NMX-1POS-STM1H) Appearance and Indicators Appearance of 1-port POS module (NMX-1POS-STM1H) This module has the status indicator for POS port and the sub-card Ready indicators. Each POS port has two status indicators: Link and Alarm.
  • Page 36 Hardware Installation and Reference Guide Overview Interface rate 155.52 Mbps Short-haul Medium-haul Long-haul single Ultra long-haul Type Output multimode single mode mode single mode optical Minimum -20.0 dBm -15.0 dBm -5.0 dBm -5.0 dBm power Maximum -14.0 dBm -8.0 dBm 0 dBm 0 dBm Receiver sensitivity...
  • Page 37 Hardware Installation and Reference Guide Overview Attributes of the NMX-6FEH The NMX-6FEH module provides 6 10/100Mbps Ethernet interfaces, which adopt the RJ45 connector. The basic attributes are as below:  NMX-6FEH 802.3-2000 standard Protocol Number of interfaces Interface type 10Base-T/100Base-TX interface Operating temperature: 0°C ~45°C Environment index: Storage temperature: -20°C ~70°C...
  • Page 38 Hardware Installation and Reference Guide Overview Brown-white Brown-white Brown Brown Introduction to Power Modules RG-PA240R Power Module RSR30-44 supports at most two RG-PA240R power modules Appearance and Indicators Appearance of RG-PA240R It has three status indicators: IN, OUT, and FAIL. ...

  • Page 39: Rich Protocol Support

    Hardware Installation and Reference Guide Overview Appearance and Indicators Appearance of RG-RSRXX40-FAN fan tray module It has two status indicators: Fan_Status and Fan_Power  Fan_Status: Green on means normal operation of the fan tray; Red on abnormal.  Fan_Power: ON means normal operation of the fan tray power; Red on abnormal. Module Attributes Its attributes are as follows: Number of fans...
  • Page 40 Hardware Installation and Reference Guide Overview  Supports DHCP Server, DHCP Client, DHCP Relay, and TFTP.  Supports back up and VRRP for high reliability.  Supports PPPOE.  Supports static DNS and DDNS.  Supports X-MODEM upgrade by asynchronous FTP. ...

  • Page 41: Easy Upgrade

    Hardware Installation and Reference Guide Overview Easy Upgrade  Supports X-MODEM and downloading new versions through the Console or synchronous port in various operating systems (Windows 95, Windows NT, UNIX, and DOS)  Supports downloading new versions by TFTP  Supports BOOTROM online upgrade...

  • Page 42: Preparation Before Installation

    Replacing incorrect battery models might lead to potential explosion risks. Please follow the product instruction to dispose waste batteries. Requirements on Installation Environment Ruijie routers are for indoor use only. To ensure their normal operation and prolong their life span, the installation site should meet the following requirement: ...

  • Page 43: Cleanness Requirements

    The electrostatic attraction is easier to occur when the relative humility is low. The following table gives Ruijie routers' requirements on dusts density and diameter in equipment room. Maximum diameter (µm) Maximum content (number of particles 1.4 x 10...

  • Page 44: Anti-Interference Requirements

     There is enough room at the inlet wind gap and the vent of the router for heat dissipation of the cabinet. Ruijie families of routers are equipped with fans. They draw in cold air from the radiating holes around the frame and exhaust it from under the frame.
  • Page 45 Configuration cables  Ethernet cables  Module interface cables The power cables, configuration cables and connectors are supplied along with Ruijie routers. The Ethernet cables and module interface cables need be purchased separately. The relative devices include:  Hub or switch ...

  • Page 46: Router Installation

    Hardware Installation and Reference Guide Router Installation Router Installation Procedure for Installing Router Please follow the following procedure to install the router to ensure the smooth installation and avoid any damage to the unit: Mounting the Router Now the router is ready for installation. Mount it to either of these two places.

  • Page 47: Installing Power Module

    Hardware Installation and Reference Guide Router Installation  A cabinet  A workbench Mounting the Router to Cabinet RSR30 series routers is designed for 19-inch standard cabinets. Use the supplied fixing accessory for installation when needed. Mounting the Router to Workbench In the absence of a 19-inch standard cabinet, install the router to a clean workbench.
  • Page 48 Hardware Installation and Reference Guide Router Installation Removing Router Power Module This part deals with the removal of the RSR30 series routers. The module to be installed is the RG-PA240R power module. Place the router in such a way that you face the rear panel of its host. Switch off the power module to be removed and leave the switches of other power modules on.
  • Page 49 Hardware Installation and Reference Guide Router Installation Press the fan tray module against the barrier on the right side of the slot where the fan tray module is to be installed. Drive the fan tray module into the router host till it is in close contact with the back panel. Tighten the fastening screw on the fan tray module with a cross screwdriver.
  • Page 50  When removing the control module, keep a distance from the aisle of the workshop to prevent the removed module from being knocked off or accident caused by collision. Installing Power Cable and Grounding Cable Ruijie families of routers support this AC power supply. AC: 100–240V 50/60Hz Make sure that your power supply meets the requirement.

  • Page 51: Connecting Console

    Turn the router to power on position. Check the power indicator on the front panel is on. If it is, it means that the power cable is correctly connected. Connecting Console Ruijie series routers supply an EIA/TIA-232 configuration console for local configuration. Configuring attributes RJ-45...
  • Page 52 Hardware Installation and Reference Guide Router Installation Repeat steps 3 through 5 till you have installed all of the functional modules. Before installing router modules, mark sure all power supply connected to the router is switched off. Otherwise, electric shock or device damage may occur. In Steps 3 and 4 be careful and insert the module gently and smoothly.

  • Page 53: Installation Check

    Hardware Installation and Reference Guide Router Installation Installation Check When you have installed the router, before powering on it, do as follows:  If the router is stalled in a cabinet, check the installation brackets of the cabinet and router are firm. If the router is stalled on the workbench, check there is enough room around the router for heat dissipation and the workbench is firm.
  • Page 54 Hardware Installation and Reference Guide Router Startup and Configuration Router Startup and Configuration Starting Router Building Configuration Environment When you use the router for the very first time, you will need to configure the router through a console port as follows: As illustrated below, connect the serial port of a character terminal or microcomputer to the console port through a RS232 cable.

  • Page 55: Starting Process

    Hardware Installation and Reference Guide Router Startup and Configuration Before powering on the router, check the position of the power switch so that you may cut power supply in time in case of accident. Powering on Router Turn the router to the power on position. Check after Powering on After powering on the router, please check: ...
  • Page 56 Ruijie General Operating System Software Release Software (tm), RGOS 10.4(3) Release(105464), Compiled Tue Dec 28 09:47:21 CST 2010 by ngcf66 Copyright (c) 1998-2010s by Ruijie Networks. All Rights Reserved. Neither Decompiling Nor Reverse Engineering Shall Be Allowed. Hardware Calendar (RTC) Error.

  • Page 57: Configuring Router

    Hardware Installation and Reference Guide Router Startup and Configuration When using the router for the first time, it is recommended setting basic parameters using the configuration function. Configuring Router Before using the router, you will have to configure it as needed. For more information on router configuration, see the related Configuration Guide and Command Reference.

  • Page 58: Troubleshooting Power Supply

    Hardware Installation and Reference Guide Troubleshooting Troubleshooting Troubleshooting Power Supply For the RSR30 series routers, you may use the power indicator on the front panel and the status indicator on the power module to decide if the power supply system is operating normally. For description of indicators, see Chapter 1. If a fault occurs, check ...
  • Page 59 Hardware Installation and Reference Guide Troubleshooting If illegible characters appear on the terminal, this may be caused by mismatched terminal parameter setting. Check if baud rate is set to 9600, databit to 8, stop bit to 1, parity to No, flow control to No and terminal emulation type to VT100. When the console port parameters of your router are modified, this may also lead to no display on the terminal.
