Installation Manual
The SIC-4ESW is the Class D line card, which can be used by the slot marked with "D".
The interface card includes one RDY indicator, and four RJ45 connectors, each with one
LINK indicator and one ACT indicator.
Panel indicator description:
Link
RDY
ACT
1.3.5.2
Attributes of the SIC-4ESW Card
The basic attributes are as below:
SIC-4ESW
Number of ports
Interface type
Cable
Standard compliance
Operating Temperature:
Humidity
EMC
1.3.5.3 Module Cable
The SIC-4ESW module uses standard non-shield Cat-5 twist pairs.
No router cables are shipped with the routers and need to be ordered separately.
According to different using conditions, the Ethernet cables can be divided into two types:
straight cable and crossover cable, .
Indicator
Solid on means the link is through, OFF not connected.
ON means the sub-card initialization after power on is done.
OFF means the sub-card initialization after power on is
unsuccessful.
Flash means data is transmitting on the port.
OFF means no data is transmitting on the port.
Four
Four RJ45 connectors
Non shield Cat-5 twisted pairs
IEEE 802.3
Operating temperature: 0°C ~45°C
Storage temperature: -40°C ~70°C
Operating humidity: 10%~90%
EMI: GB 9254-1998 Class A
EMS: GB/T 17618-1998
Chapter 1 Product Overview
Description
