Installation Manual
6

Cable Connection

This chapter indroduces the use of various cables and converter adapters.
6.1

Physical Cable Connection

6.1.1

Connecting An Asyn Interface

6.1.1.1 Connecting An Asyn Interface Module to A
Modem
As a DCE equipment, the modem has two kinds of serial interfaces: DB9F and DB25F.
Connecting the asyn interface to Modem
The asyn cable with 1-to-8 crystal connector converts the 68-pin connector of the asyn
interface into eight RJ45 connectors, and then connects to the DB25F interface of the
modem through the RJ45(crystal jack)-DB25 male converter.
When the asyn cable with 1-to-8 crystal jack is used, use a straight netwok cable to connect
the converter cable of the asyn interface module to the converter adapter.
This mode applies to such modules as NM-8A/16A and SIC-8A.
Table 6-1 Connect the asyn interface module to Modem
Equipment
NM-8A/16A
SIC-8A
Connect the AUX interface to Modem
The AUX port is connected to Modem through a rollover cable with RJ45(crystal jack)-DB25
male converter or RJ45-DB9 male converter.
Cable 1 Cable 2
Asyn cable RJ45(crystal
with 1-to-8 jack)-DB25
crystal male
connector converter
Asyn cable
Straight
with 1-to-8
cable
crystal jack
Chapter 6 Cable Connection
Cable 3 Peer
/
DB25F interface of the
Modem
RJ45(crystal
jack)-DB25
male converter
6-1
